Sistema de recipiente de envejecimiento a presión PAV

Main technical features

1. This system is composed of PAV-1-1 pressuring aging vessel and PAV-1-2 aging vacuum vessel.

2. This system is equipped with a PC which controls all test procedures include high pressure aging test.

Main technical specifications

(1) PAV-1-1 pressuring aging vessel

1.Electricity

Power supply：          AC（220±10%）V, 50Hz

Rated power：          1100W

Rated current：          10A

2.Vessel

Volume：             13L

Medium：             Air

Rated working temp.：        110℃±5℃

Rated working pressure：       2.1MPa

Designed pressure：          2.2 MPa

Water pressure：            2.75 MPa

    Safety valve opening pressure：  2.15 MPa

Explosive pressure for rupture disk： 2.6 MPa

3. Pressure controller

Model：              WP962-2(WP-D90)

Precision：             ±0.01MPa

4. Temperature and time controller        Model WP962-1(WP-D90)

Temperature control precision：    ±0.1℃

Grading：              64×1080min

Outage maintaining function：     Yes

Dimension                                               630mm×450mm×500mm

（2）PAV-1-2 aging vacuum vessel

1.Electricity

Power supply：          AC（220±10%）V, 50Hz

Rated power：           900W

Rated current：              10A

2.Vessel

Volume：             13L

Medium：             Air

Rated working temp.：        180℃±5℃

Rated working pressure：      Absolute pressure 15kPa

Pressure control mode：       Electric contact pressure gauge

3. Temperature and time controller      Model XMT-E55T2

Temperature control precision：   ±0.1℃

Time control mode：        Button

4. Dimension                                      560mm×390mm×350mm
